    UHMWPE (Ultra High Molecular Weight Polyethylene) Fiber is the Lightest and Strongest High Performance Polyethylene Fiber.

    UHMWPE Fiber that is 15 times stronger than steel & 40% stronger than aramid fiber at the same weight.



    Industry & Automobile

    Marine & Shipping

    Medical

    Protective & Safety

    Sports & Lifestyles

    Wire & Cable

    UHMWPE Properties

    PropertyTypical
    Specific Gravity0.97g/cm3
    Melting Temperature144-152℃
    Moisture RegainNone
    Affected by WaterNo
    Resistance to AcidsExcellent
    Resistance to AlkaliExcellent
    Resistance to ChemicalsExcellent
    Resistance to UV-LightExcellent



    Multifilament

    DenierTenacity(Min.)Modulus (Min.)
    3036~42g/d1300~1500g/d
    4036~42g/d1300~1500g/d
    5036~42g/d1300~1500g/d
    10036~42g/d1300~1500g/d
    15036~42g/d1300~1500g/d
    20036~42g/d1300~1500g/d
    25035~40g/d1300~1500g/d
    30035~40g/d1300~1500g/d
    35035~40g/d1300~1500g/d
    40035~40g/d1300~1500g/d
    50035~40g/d1300~1500g/d
    60034~39g/d1300~1500g/d
    80034~39g/d1300~1500g/d
    100034~39g/d1300~1500g/d
    120034~39g/d1300~1500g/d
    160034~39g/d1300~1500g/d
    240033~37g/d1300~1500g/d
    320032~36g/d1300~1500g/d



    Application in Sea, on Land, on Sky

    ●  Ropes & Cordages
    ●  Ballistic Fabrics
    ●  Cut Resistant Gloves
    ●  Fishing Lines
    ●  Specialty Fabrics
    ●  Slings
    ●  Nets
    ●  Cooling Fabrics
    ●  Helmets



    WEBTEX has the world’s largest UHMWPE yarn color library, the available  deniers are from 30D to 3200D.

    Good spinnability Soft feel, cool feel, moisture absorption & comfortable
    Abrasion resistance, tear resistance, anti-cut

    DenierLength
    1.1
    		38mm
    1.151mm
    1.738mm
    1.751mm

    Applications

    Non-woven

    Non-woven apparel fabric

    Non-woven filtering fabric

    Non-woven cut resistance fabric

    Blending with cotton

    Improving the properties of mechanical, abrasion resistance and weatherability of cotton products.

    Covered Yarn

    Soft feel, cool feel, moisture absorption & comfortable
    Abrasion resistance, tear resistance, anti-cut, anti-puncture & corrosion resistance

    DenierMaterialGrade
    605DUHMWEP Fiber+PET+Glass Fiber EN388:2003 Lever5
    777DUHMWEP Fiber+PET+Glass Fiber+SpandexEN388:2003 Lever5

    Applications

    Cut-resistant Clothes, Gloves and Bags.

    UD Sheet

    Soft Ballistic UHMWPE UD Sheet

    WEBTEX UHMWPE UD is combined with specially resin base and UHMWPE fiber. It’s mainly used in soft bulletproof field, with advantages of lightness, softness, and excellent wearing comfort; light weight will also work with good protection against shooting in various environments.
    21~49 layers, NIJ IIIA (Contact us for more information)



    Hard Ballistic UD Sheet :

    UHMWPE Hard Ballistic UD Sheet is the best choice for light-weight GA141 level 5 and level 6, NIJ III and IV ballistic plates, shields, and vehicle armors.
    The mainly application is used in bulletproof inserted plate, bulletproof armored vehicle, bulletproof shield, bulletproof walls.
    It is with excellent anti-fragment performance, greatly reducing the depression. Due to the very low dielectric constant of UHMWPE fiber, the equipment will have stealth effect for covering the important parts of the warship, tank, battery and etc.



    Cut Resistance Glove

    ModleStructurePerformanceColorWeight (g/pair)Size
    WT10553UHMWPE+PET/PA+PUEN-388 Level 3White52.5g (L)8(M), 9(L), 10(XL, 11(XXL)
    WT10555UHMWPE+PET/PA+PUEN-388 Level 3Grey58.6 (XL)8(M), 9(L), 10(XL, 11(XXL)
    WT10590UHMWPE+Glass Fiber+PUEN-388 Level 5Grey76g (XL)8(M), 9(L), 10(XL, 11(XXL)
